High Security ANSI Standard Tubular Knob lock (6870SS-DM)

6870SS-DM

Tubular Knob Series-Square-Drive Spindle

Special Design for Standard Duty.

Meets with ANSI A156.2 Grade 3. Exceeds 200,000 cycles.

•      Door Prep: Cross bore 2-1/8"(54mm),Edge bore 1"(25mm), Latch face l"x2-l/4" (25x57mm).

•      Door Thick: Fit doors 1-3/8"(35mm) to 2"(50mm) thick.

•      Backset: Adjustable 2-3/8" (60mm) or 2-3/4"(70mm).

•      Handing: Completely reversible.

•      Faceplate: Changeable Square corner l"x2-1/4"(25x57mm) standard, radius comer also available.

•      Strike: Full lip D-shape 1-3/4"x2-l/4" (44x57mm) square standard, radius corner also available.
